ART 312-A MK4

ACTIVE TWO-WAY SPEAKER
  • 128 dB Max SPL
  • 800 WATT 2-way peak power
  • DSP Processing with FiRPHASE
  • 12" woofer, high power 2.5" voice coil
FiRPHASE
Support
Features
  • 128 dB Max SPL
  • 800 WATT 2-way peak power
  • DSP Processing with FiRPHASE
  • 12" woofer, high power 2.5" voice coil
  • 1" HF driver, mylar dome, 1.5" voice coil

Active speakers for live sound reinforcement and stage monitoring as well as distributed sound systems for clubs, music venues and corporate events. ART 312-A MK4 is the optimum choice for live sound situations where an exceptional full range, outstanding bass reproduction and accurate high frequency delivery are required

ARCHIVED

Part number:

13000539
ART 312-A MK4
220-240V, EAN 8024530014797

13000540
ART 312-A MK4
115V, EAN 8024530015190

Specifications
Acoustical specifications
Frequency Response:
50 Hz ÷ 20000 Hz
Max SPL @ 1m:
128 dB
Horizontal coverage angle:
90°
Vertical coverage angle:
60°
Transducers
Compression Driver:
1 x 1.0'', 1.5'' v.c
Woofer:
12'', 2.5'' v.c
Input/Output section
Input signal:
bal/unbal
Input connectors:
XLR, Jack
Output connectors:
XLR
Input sensitivity:
-2 dBu/+4 dBu
Mic. Input Sensitivity:
-32 dBu
Processor section
Crossover Frequencies:
1800 Hz
Protections:
Thermal, RMS
Limiter:
Soft Limiter
Controls:
Volume, Boost, Mic/Line
Power section
Total Power:
800 W Peak, 400 W RMS
High frequencies:
200 W Peak, 100 W RMS
Low frequencies:
600 W Peak, 300 W RMS
Cooling:
Convection
Connections:
VDE
Standard compliance
Safety agency:
CE compliant
Physical specifications
Cabinet/Case Material:
PP Composite
Hardware:
4 x M10
Handles:
1 Top, 2 Side
Pole mount/Cap:
Yes
Grille:
Steel
Color:
Black
Size
Height:
680 mm / 26.77 inches
Width:
405 mm / 15.94 inches
Depth:
345 mm / 13.58 inches
Weight:
16.8 kg / 37.04 lbs
Shipping information
Package Height:
406 mm / 15.98 inches
Package Width:
466 mm / 18.35 inches
Package Depth:
798 mm / 31.42 inches
Package Weight:
19.8 kg / 43.65 lbs
